Electric Kart for Kids

SKU :UNKNOWN SKU PLS CONTACT WEBMASTER.

Add Date : 2018-07-13  |  Print
Other Cate ：
  • Products Size………………………920X400X720mm
  • Motor Type …………….brushed DC , 250W/24V
  • Motor Max Loaded Amps……………..17.8A
  • Torque………………1.21（N.m）
  • Max RPM……………..2700±7.5%(rpm)
  • Controller Type..Air cooled, non water -proof; brake shutoff, charger port
  • Battery…………….Lead-Acid Battery,12V /7AH*2pcs
  • Charging Time………………….6-8 hours
  • Battery Charger…..Input-100-240VAC,50/60HZ,1.8A Max; Output-DC 24V,1.5A
  • Special Features………….Dismountable Handle bar
  • Turning Angle………………………..32º
  • Turning Radius…………….≤1400mm
  • Transmission Ratio…………92/11
  • Seat Height……………….340 mm
  • Wheel base Distance ………….635 mm
  • Front & Rear Tire and Rim ………110/50-6.5
  • Maximum Carrying Capacity………….45kgs
  • Mini Ground Clearance………………….90 mm
  • Maximum Speed………………..Low speed: 11km/h; high speed:21 km/h
  • Maximum Distance Range…….13 km
  • Control System……………….handle bar control
  • Throttle Type…………………turn control
  • Front & Rear Braking System……..Mechanical disc, left handle control
  • Drive System……………………….Chian drive
  • Brake Distance…………………….≤2m (11km/ h); ≤4m (21km/ h)
  • Packing Size……………………….950mmx285mmx520mm
  • N.W/G.W………………………….23kgs/26kgs
